INTRODUCTIONThe 558 is a monolithic Quad Timer designed to be used in thetiming range from a few microseconds to a few hours. Four entirelyindependent timing functions can be achieved using a timing resistorand capacitor for each section. Two sections of the quad may beinterconnected for astable operation. All four sections may be usedtogether, in tandem, for sequential timing applications up to severalhours. No coupling capacitors are required when connecting theoutput of one timer section to the input of the next.FEATURESã 100mA output current per sectionã Edge-triggered (no coupling capacitor)ã Output independent of trigger conditionsãWide supply voltage range 4.5V to 16Vã Timer intervals from microseconds to hoursã Time period equals RCCIRCUIT OPERATIONSIn the one-shot mode of operation, it is necessary to supply aminimum of two external components (the resistor and capacitor) fortiming. The time period is equal to the product of R and C. An outputload must be present to complet...
